Action 4 lightweight wheelchair

Action 4 is a lightweight, comfortable, and stable folding frame wheelchair with a with a wide variety of additional options

The Action 4NG lightweight is a stable folding frame wheelchair
Priced from R36,650.00

made to specs pre-order

Action 4 lightweight stable folding frame wheelchair
Invacare Action 4 is a lightweight, comfortable, and stable folding frame wheelchair
with a robust and durable double cross brace folding mechanism.

Action 4NG lightweight wheelchair has Flip back armrests, adjustable backrest angle,
swing away/removable footplates and wide variety of additional options
and configurations make the Action 4NG a versatile and practical solution.

1.Enjoy the ride

The double cross brace system improves stability and comfort during the drive while offering an easy foldable wheelchair.

2.Unique backrest foldable mechanism

The innovative, patented, angle adjustable backrest available in option enables users to fold the backrest on top of the seat for easy storage or transportation in a car.

3. Angle adjustable legrests

Combining length compensation with 0-80° elevation, this option enables pressure relief and optimal comfort position.

As with all models in the Action NG family,
all parts are cross compatible and interchangeable
throughout the range whether you have an Action NG 2, 3 or 4.

All these changes have created a modern, practical, and manual wheelchair that allows the user to easily transport it in any vehicle and store it anywhere.

This wheelchair also has various choice of cushions to improve the user’s position and prevent bedsores.

In addition, its removable armrests can be always adapted to the user’s needs.

The Action 4NG has been fully crash tested and is available in 8 attractive frame colours.

Do not try to fix or replace any wheelchair part if you don’t feel comfortable doing it.
Make plans to have the wheelchair serviced once a year!
Service and Repairs – Wheelchairs on the Run

Features: of the Action 4 lightweight wheelchair

- Nylon Seat Upholstery
- Swing away/removable flip-up footplates
- Flip back desk-style armrests
- Choice of 8 Colours
- Optional push or pull to lock brakes
- Transportation kit and buckle belt
- Adjustable heel straps
- User tool kit

All size measurements in centimetres (cm)

Seat Width: 38 / 40.5 / 43 / 45.5 / 48 / 50.5 / 55.5 / 60.5
Seat Depth: 40 / 45 / 50
Seat Height: 36 / 38.5 / 41 / 43.5 / 46 / 48.5 / 51

Backrest Height:
40 / 43, adjustable (Fixed/Folding) (Standard)
38 to 46, adjustable (Fixed/Folding) (Standard)
51 (Fixed) (Standard)
39 / 41 / 43, adjustable (Reclining) (Optional)
47 / 49 / 51, adjustable (Reclining) (Optional)
43 / 51 (Folding) (Optional)

Backrest Angle:
0° (Fixed, Folding) (Standard)
7° (Fixed) (Standard)
0° to 30°, adjustable (Reclining) (Optional)
-15° to 15°, adjustable (Folding) (Optional)

Front Frame Angle:
80° (Standard)
0° to 80°, adjustable (Optional)

Footplate Distance: 20 to 40 / 33 to 46 / 44 to 51, adjustable
Camber: 0° / 3° / 6°

Maximum User Weight: 125 kg

Total Length: 99.5 to 117
Total Width: Seat Width + 19 cm approx
Total Weight: 14 kg
Weight without Rear Wheels: 8 kg
Encumbrance (minimum width when folded): 30.5
